Audio Control LC6i

Features
High Current 12-Volt Trigger Output
Internal Channel Summing
GTO™ Signal Sensing Inputs
Speaker Level Inputs – Can Accept 400 Watt Signals!
Level Matching Controls
Six Input and Output Channels
AutoMode™ Turns 4-channel Input into 6-channel Output
Input for Optional Subwoofer Level Control

Specifications:

Inputs
Speaker Level Input: 3 (6 channels)
Maximum Speaker Level Input: 400W per channel at 4Ω
Input Impedance: 20kΩ

Outputs
Preamp Outputs: 3 (6 channels)
Maximum Output Level: 9.5Vrms
Output Gain: ±12dB

Performance
Total Harmonic Distortion: 0.01%
Frequency Response: 10 Hz to 22 kHz

Control
Remote In
12VDC Remote Out (always active when unit is on)

General
Power Supply: High Headroom PWM Switching
Current Draw: 200mA
Recommended Fuse Rating: 1A

Weights & dimensions
Dimensions: 8”W x 6”D x 1.2”H
Weight: 2.0 lbs (0.9 kg)

In the box: LC6i, Speaker and Power connectors, Manual, Warranty
