JL Audio 15W0V3-4
JL Audio 15W0V3-4
GamintojasSkersmuo15" (381mm)-
Continuous Power Handling (RMS) 500 W
Recommended Amplifier Power (RMS) 150 - 500 W
Nominal Impedance (Znom) 4 Ω
Nominal Diameter 15.0 in / 380 mm
Overall Diameter (A) 15.5 in / 394 mm
Mounting Hole Diameter (B) 13.75 in / 349 mm
Bolt Hole Circle Diameter (C) 14.56 in / 370 mm
Motor Outer Diameter (D) 6.3 in / 160 mm
Mounting Depth (E) 7.15 in / 182 mm
Driver Displacement 0.109 cu ft / 3.09 L
Net Weight 15.8 lb / 7.2 kg
