Mosconi PRO5/30

TECHNICAL DATA MOSCONI PRO 5|30

OUTPUT POWER:
Output power @ 4Ω: 2 x 95 + 2 x 185 + 1 x 660 Watts
Output power @ 2Ω: 2 x 150 + 2 x 290 + 1 x 1030 Watts

SPECIFICATIONS:
Input sensitivity: 0.35 V ÷ 12 V (5.3 V in DDSP mode) [CH 1/2/3/4]
                          0.14 V ÷ 5.9 V (3.1 V in DDSP mode) [CH 5]
Dimensions: 500 x 205 x 55 mm
Weight: 5,4 kg
Crossover: CH 1/2 = HP: 43 ÷ 500 Hz (x 1) or 430 ÷ 5000 Hz (x 10)
                  CH 3/4 = HP: 50 ÷ 200 Hz & LP: 430 ÷ 5000 Hz
                  CH 5 = LP: 43 ÷ 200 Hz
Signal to Noise Ratio: > 83 dBA (ref: 1 Watt into 4 Ohm)
