Features:
Class A/B Amplifier Designs
APP Control for iOS & Android (Coming 2025)
Bluetooth 5.0 Built-in
Burr Brown DAC
Input Priority
OIS - OEM Impedance Simulation
Plug & Play Optimised
Type: DSP Amplifier
Amplifier Class: A/B
Amplified Channels: 4
DSP Channels: 8
Frequency Response (-3dB): 15Hz ~ 23kHz
MAX Power Rating: 560W
RMS Power Rating (2Ω): N/A N/A N/A
RMS Power Rating (4Ω): 4X70W
RCA Voltage Output: 4V
DAC: Burr Brown PCM1681
DSP Resolution: 24 Bit
Sampling Rate: 48kHz
SNR (Analogue/Digital Input):-90dB
THD: 0.1%
Crosstalk:-60dB
Damping Factor: 120
High-Level Input: Yes
Auto Turn-On: Yes
Input Sensitivity (High-Level): 0.2V - 20V
Input Sensitivity (Low-Level): 0.2V - 5V
Operating Voltage: 9V - 16V
Start-Stop Compatible: Yes
Idle Current: 1.5A
Current Draw (MAX): 30A
Total Efficiency (4Ω): 60%
Power Terminal: 10mm²
Remote (Optional): ZDAWCT
Low-Level Outputs (RCA): 8
Analogue Inputs: 6 x High-Level / 2 x Low-Level
Digital Inputs: Bluetooth / Coaxial / USB / SPDIF
Remote Input: Yes
Remote Output: Yes
PC Connection Input: USB-B
APP Control (Coming Soon): Yes
PC Software: Yes (Windows 10, Windows 11)
APP: Yes (Coming Soon)
Equalizer: 31-Band
Phase Adjustments: 0 or 180 degree
Filters: High-Pass & Low-Pass
Filter Types: Bessel, Butterworth, Linkwitz-Riley
Filter Slopes (Bessel/Butterworth): Off, -6dB, -12dB, -18dB, -24dB, -36dB, -
42dB, -48dB
Filter Slopes (Linkwitz-Riley): Off, -12dB, -24dB, -48dB
Time Alignment: 0 - 48ms (0 - 1632cm)
Bypass EQ: Yes (Individual channels & ALL channels)
Mute: Yes (Individual channels & ALL channels)
Input Priority: Yes (2 Sources)
Turn-On Delay: Yes (5 - 30sec)
Custom Signal Routing: Yes
EQ Settings: Graphic EQ / Parametric EQ
Delay Calculator: Yes (cm and inches)
Delay Unit: Centimeters / Inches / Milliseconds
Custom Link Settings: Copy & Relate (Delay/EQ/Filters/Volume)
Input Setting (Input Sensitivity):-6dB, -3dB, 0dB, +3dB, +6dB
Preset Password Protection: Yes
Full Screen Mode: Yes
EQ Band Gain: (Each EQ Band)-12dB to +12dB
Adjustable Q Value: 0.1 to 12
Languages: English, German, Spanish & Chinese
EQ Adjustable Frequency Range: 20Hz - 20kHz
Individual Channel Gain: 0dB to -59dB
Global Volume Gain: 0dB to -28dB
Selectable Channel Names: Yes, for each channel
