Specifications:
Speaker Type: Midrange
Speaker Size: 3.5″ (89mm)
Impedance: 8Ω
Frequency Response: 250Hz – 10kHz
Power Handling (RMS): 20W
Power Handling (MAX): 40W
Sensitivity: 86dB (1W/1m)
Re: 6 Ohm
Fs: 116Hz
Qms:12.236
Qes: 1.366
Qts: 1.229
Cms: 633.799 uM/N
Vas: 1.258 L
BL: 3.082 Tm
Sd: 3.739 cm2
Mms: 2.964 g
0.8″ (20.4mm) Voice Coil
Paper cone with rubber surround
Ferrite magnet
350/4000Hz Band-pass filter (6dB/Oct) for ZX35C (for use in a 3-way system)
350Hz Low-pass filter (6dB/Oct) for the midbass in a 3-way system
Mounting Depth: 40mm
Mounting Diameter: 86mm
Outer Diameter: 89mm
Sold as Pair
